Job Card D/R A233 - Lift Screw Assembly Top Brake
Page no. 1285 Chapter 9
JC-DR-A-233.fm
route it directly upwards towards the brake. Use cable ties to secure the Lift screw Assembly Top
Brake cable (W510) up the side of the Gantry as shown below. Gather the excess cable at the end of
J6
To Brake
