Chapter 9 Page no. 1302
JC-DR-A-246.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A246 - Manual Compression Brake
6 PROCEDURE
6-1 Disassembly of the Manual Compression Brake
1. Remove the belt (1) (refer to Job Card D/R A245 - Manual Compression Belt on page 1299).
2. Remove the M6 screw (2) (5 mm allen wrench).
3. Release the four pairs of M4 screws (3) (3 mm allen wrench). Then and carefully remove the Paddle
1
2
