GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A292 - Tube Tilt Pivots
Page no. 1399 Chapter 9
JC-DR-A-292.fm
7 COMPLETION
1. Switch ON the Gantry.
2. Switch ON the electrical power supply from the Mains Distribution Panel in the room.
Note:
Before performing the calibrations and checks listed below, carry out a detector clear calibration.
From the Service Desktop, click the Calibrations button, then select Detector and Clear Calibra-
tion.
Calibrations / Checks Job Cards
Acquisition Image Chain
Tube Tilt Calibration Job Card CAL A027 - Tube Tilt Calibration on page 1681
Collimator Calibration Job Card CAL A029 - Collimator Format Calibration on page 1683
Collimation Check Job Card ELE A028 - Collimation Checks on page 679
If Collimation Check not OK, repeat Collimator Calibration
Bad Pixel Calibration Job Card CAL A041 - Bad Pixel Calibration on page 1693
Gain calibration Job Card CAL A043 - Detector Gain Calibration on page 1697
Flat field tests Job Card ELE M032 – IQ Tools Flat Field Test on page 813
Mag Resolution Test Job Card ELE M034 - IQ Tools Mag Resolution Test on page 835
If IQ Tests not OK, repeat all calibrations from Bad Pixel
Half Value Layer Job Card CAL A046 - Half-Value Layer Measurement on page 1703
IQ Tools Composite test Job Card ELE M033 - IQ Tools Composite Test on page 821
If Composite Test not OK, repeat all calibrations from Half Value Layer
AOP: Automatic Optimization of Parameters
AOP Calibration Job Card CAL A051 - AOP Calibration on page 1723
mAs non linearity Job Card CAL A053 - mAs Non-linearity Calibration on page 1725
AOP/SNR Check Job Card ELE A038 - AOP Mode and SNR Check on page 707
If AOP/SNR Test not OK, repeat all calibrations from AOP Calibration
To Next Page
