Chapter 3 Page no. 152
Component-index.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
FRU/Component Index - Control Station
45 Cable-IDC Generator Serial link 2226613 FD
page
82
Cabl
page
322
FRU Y Trac N
45 Cable-IDC Optical fiber port 2340426 FD
page
82
Cabl
page
322
FRU Y Trac N
45
Cable-IDC SIB or Gitane 26 pin 2226621 FD
page
82
Cabl
page
322
FRU Y Trac N
45 Cable-Kit-Carthage (for V1 Con-
trol Stations)
2389287 CS V1
page 54
FRU Y
45 Cable-Kit-Carthage (For V2/V3
Control Stations)
5145683 CS V2/V3
page 54
FRU Y
45 Cable-Kit-Carthage (For V3 Con-
trol Stations)
5388869 CS V3
page 54
45 Internal Cable Set incl Ethernet
cable, etc... (for V4 Control Sta-
tions)
5388869-2 CS V4
page 54
FRU Y
45 Cable-Monitor VGA BNC (for CS
V1/V2 or a V3 Control Station
upgraded via Accelera Kit)
2390029 CS V1/V2
page 54
FD
page
82
FRU Y
45 AWS DVI Monitor Cable (for V3
Control Stations)
5177284-2 CS V3
page 54
45 Cable-SCSI VHDCI 68-HD50
(not required with computer-ADS
SB150 2299357-9 or later)
2402214 CS V1
page 54
FRU Y
45 Cable-UPS Power supply 2385793 FD
page
86
FRU N
45 VGA-DVI Adaptor 5364339 Acc
page 55
FRU Y Trac N
45 ADS-UPS Extension cable 5214756 Acc
page 55
FRU Y Trac N
45 Ferrite Block 2X1/2CYL+ENV
Z275/100M D6
2109168 Acc
page 55
FRU Y Trac N
Class Component Description Reference Comp. Loc FD Cabl CL FRU Trac D/R
