GE Senographe DS User Manual

Chapter 9 Page no. 1598
JC-DR-A-410.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A410 - Inverter Board 300-PL1
6. Switch on the electrical power supply, both from the Mains Distribution Panel in the room and on the
X10 10 mm open ended wrench X10 Brown
X11 Small screwdriver X11/X12 Brown
X12 Small screwdriver X11/X12 Brown
X13 Small screwdriver 2117977: G1 (from lower hole) Brown
X14 Small screwdriver 2117977: K1 (from lower hole) Brown
X15 Small screwdriver 2117977: G1 (from upper hole) Brown
X16 Small screwdriver 2117977: K1 (from upper hole) Brown
Connec-
tor Label
Tool Description of cable
(usually identified by code on a white label)
Cable
color
X8
X6
X9
X3
X4
X2
X5
X1
X10
X7
X14 X13
X16
X15
XJ1
X11
X12
