GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A411 - Mains Distribution Board 200-PL1
Page no. 1603 Chapter 9
JC-DR-A-411.fm
WARNING
Residual voltage stored in the C1, C2, C5, C6, C7, and C8 capacitors (located behind the
Mains Distribution board can be dangerous. Ensure that the capacitors are fully dis-
charged before you handle the Mains Distribution board.
C1
C5
XJ8
XJ9
C7
C8
C6
C2
