GE Senographe DS User Manual

GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Central Listing
Page no. 249 Chapter 3
Indicators and Switches.fm
2-2-4. Generator Interface Board 400PL2 Test Points
Test Point Label (in French) Function (in English)
TP1 Cons_Chauf_A Requested Heater A Current
TP2 Cons_Chauf_B Requested Heater B Current (Ground)
TP3 T5000 5000 RPM Speed
TP4 Entretien Normal Rotation Speed
TP5 Marche_Lanceur Starter Working
TP6 Freq_Polar Polar Frequency
TP7 kV_Vide kV Empty
TP8 Pose_Rx X-ray Exposure
TP9 Marche_Chauf Heater Working
TP10 Piste_2 Track 2
TP11 mA_Max Maximum mA
TP12 kV_INF_5_B
TP13 Strobe_kV_A
TP14 SRI_kV_A
TP15 Load_kV_A
TP16 Load_kV_B
TP17 Voyant_Pose_A Exposure Warning A
TP18 0V_Pupitre X-ray Console 0V
TP19 Button Prepare
TP20 mA_A
TP21 Rx +
TP22 Rx -
TP23 Tx -
TP24 Frein Brake
TP25 Alim_Puis_OK Power Supply OK
TP26 Secu_RatTrap
TP27 Pres_Supply Supply Present
TP28 Pres_Chauf Heater Present
TP29 Lect_Secu
TP30 Marche_Polar Polarization Working
TP31 Pres_Polar Polarization Present
TP32 Pres_Rotat Rotation Present
TP33 En_Pose On Exposure
TP34 Secu_Bloq Blocking Security
TP35 Timeout_Regul Timeout Regulation
TP36 Trad
TP37 mA_B
TP38 Strobe_kV_B
