Chapter 3 Page no. 248
Indicators and Switches.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Central Listing
DS14 +12 V Present Green ON when the +12 V from the Generator Command
Board 400PL1 is present and functioning as
expected.
OFF when the +12 V from the Generator Command
Board 400PL1 is not present. In this case, check
the status of the green DS9 LED on the Generator
Command Board 400PL1.
• If the DS9 LED on the Generator Command
Board 400PL1 is ON, change the cable between
the XJ9 connector on the Generator Command
Board 400PL1 and the XJ1 connector on the
Generator Interface Board 400PL2.
• If the DS9 LED on the Generator Command
Board 400PL1 is OFF, follow the appropriate trou-
ble shooting steps for that LED as described in
Mains Distribution Board 200PL1 LEDs on page
264.
DS15 Authorization Working Red ON when security is inhibited.
OFF when X-ray Exposures is prohibited.
To Next Page
