GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Central Listing
Page no. 257 Chapter 3
Indicators and Switches.fm
TP39 125 kHz LC Clock 125 kHz
TP40 Reset_Detect
TP41 Reset B21/1
TP42 Under Int saved LC
TP43 Brake LC
TP44 Presence_Rotation Rotation Presence
TP45 H500 (clock)
TP46 Vcc (+5 V)
TP47 H62_5K (clock) Clock 62.5 kHz
TP49 H250K (clock) Clock 250 kHz
TP49 H4M (clock) Clock 4 MHz
TP50 H2M (clock) Clock 2 MHz
TP51 Presence_Polarisation Polarization Presence
TP52 12 V BT Supply
