2-3-5. Generator Command Board 400PL1 Test Points
Test Point Label (in French) Function (in English)
TP1 Surcharge_Filament Filament overload
TP2 Measure_Phase_1
TP3 Measure_Phase_3
TP4 ICH_Carre RMS Health Current
TP5 Consigne_ICH_Carre RMS Health Current Reference
TP6 Output B13/8
TP7 Input B8 (auto_regul_ch)
TP8 Measure_Phases
TP9 Reset ADR
TP10 C_T6
Stator Command Signals
TP11 B_T6
TP12 C_T5
TP13 B_T5
TP14 C_T4
TP15 B_T4
TP16 C_T3
TP17 B_T3
TP18 C_T2
TP19 B_T2
TP20 C_T1
TP21 B_T1
TP22 Output B13/6
TP23 Clock B6
TP24 SEL_LC
TP25 Auto_Regul_Ch
TP26 Measure_Phase_TTL
TP27 Output_B16 (ICH_OND)
TP28 Fil_Coupé Filament Cut
TP29 Surcharge_Detectee Overload Detected in Filament
TP30 Marche_Chauffage (dealye) Heater Working (delay)
TP31 Output B24/10
TP32 Presence_Chauffage Heater Presence
TP33 Entretien LC Normal RPM Speed
TP34 Input B38/5
TP35 5000_LC 5000 RPM Speed
TP36 Output B35/10
TP37 Fin_Tour Tour Finish
TP38 Detect_SurInt_LC Overload Current LC detected
