GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Central Listing
Page no. 261 Chapter 3
Indicators and Switches.fm
2-5. Anode Starter Board 300PL2
2-5-1. Anode Starter Board 300PL2 Connectors
Connector Function
XJ1 To the XJ6 connector on the Generator Command Board 400PL1 (control signals)
XJ2 To Stator (U, V, W) (power phases)
XJ3 To the XJ5 connector on the Supply Command Board 200PL2 (250 V power supply)
XJ1
XJ2
XJ3
PT23
PT22
PT25
PT18
PT1
PT2
PT3
PT4
PT5
PT6
PT7
PT8
PT9
PT10
PT11
PT13
PT12
PT17
PT24PT21
PT20PT19
PT15
PT16
PT14
