GE Senographe DS User Manual

Chapter 3 Page no. 262
Indicators and Switches.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Central Listing
2-5-2. Anode Starter Board 300PL2 Test Points
Test Point Label (in French) Function (in English)
PT1 T1 Command
Command Signals
PT2 Bloc T1
PT3 T2 Command
PT4 Bloc T2
PT5 T3 Command
PT6 Block T3
PT7 T4 Command
PT8 +12 V Coupé +12 V Cut
PT9 Bloc T4
Command Signals
PT10 T5 Command
PT11 Bloc T5
PT12 Bloc T6
PT13 T6 Command
PT14 Phase 1 Phase 1 Output
PT15 Phase 2 Phase 2 Output
PT16 Phase 3 Phase 3 Output
PT17 S/T2-T4-T6
PT18 SUR_I_B Overload Current 1
PT19 0V Phase 1 0V Phase 1
PT20 Measure Phase 1 Measure Phase1
PT21 Measure Phase 3 Measure Phase 3
PT22 +250 V +250 V Present
PT23 0V/250V 250 V supply at 0V
PT24 0V Phase 3 0 V Phase 3
PT25 SUR_I_H Overload Current 2
