GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Central Listing
Page no. 283 Chapter 3
Indicators and Switches.fm
DS8 230 V to Conditioner Clear Normal status: ON/OFF
ON when the 230 V Supply going to the Condi-
tioner is present.
OFF when there is no 230 V Supply going to the
Conditioner.
DS9 Standby 12 V present via the Out con-
nector on the Low Voltage Power Sup-
ply board
Green Normal status: ON
ON when the standby 12 V from the Low Voltage
Power Supply Board is present.
OFF when there is a problem with the standby 12 V
from the Low Voltage Power Supply board. In this
case, proceed as follows:
• Check the F3 and F5 fuses on the Mains Distribu-
tion Assembly, and change them if necessary.
• If F3/F5 fuses are OK, check the F2 fuse on the
Low Voltage Power Supply Board, and change if
necessary.
• If the F2 fuse is okay, check the cable between
the XJ7 connector and the OUT connector on the
Low Voltage Power Supply Board.
• If the cable connection and F2 fuse on the Low
Voltage Power Supply Board are OK, change the
Low Voltage Power Supply Board.
