Chapter 3 Page no. 282
Indicators and Switches.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Central Listing
3-1-2. Mains Distribution Assembly LEDs
LED Function Color Behavior
DS1 240 V from Primary Transformer Clear Normal status: ON
ON when the 240 V Supply from the Primary Trans-
former is present.
OFF when there is a problem with 240 V Supply
from the Primary Transformer.
DS2 230 V ADS Clear Normal status: ON
ON when the 230 V AC supply to the Control Sta-
tion UPS is present.
OFF when there is a problem with the 230 V AC
supply to the Control Station UPS.
DS3 230 V from Primary Transformer Clear Normal status: ON
ON when the 230 V Supply from the Secondary
Transformer is present.
OFF when there is a problem with 230 V Supply
from the Secondary Transformer.
DS4 230 V DPS (APS_SPS) Clear Normal status: ON
ON when the 230 V AC supply to the Detector
Power Supply is present.
OFF when there is a problem with the 230 V AC
supply to the Detector Power Supply.
DS5 Power ON ADS Orange Normal status: ON/OFF
ON when the ADS is powered on via the Control
Station power button on the Service Interface.
OFF when the ADS is powered off via the Control
Station power button on the Service Interface.
DS6 Power ON DPS (APS_SPS) Orange Normal status: ON/OFF
ON when the Detector Power Supply is powered
ON.
OFF when the Detector Power Supply is powered
OFF.
DS7 Power ON Condtioner Orange Normal status: ON/OFF
ON when the Conditioner is powered ON.
OFF when the Conditioner is powered OFF.
