Chapter 3 Page no. 292
Indicators and Switches.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Central Listing
DS22 Relay 1 Active Yellow ON when relay 1 is active
OFF when relay 1 is idle
DS23 Relay 2 Active Yellow ON when relay 2 is active
OFF when relay 2 is idle
DS24 Reset PDU Board Red ON while the PDU board is being reset.
OFF when the PDU board is functioning normally.
DS25 Watchdog Yellow ON when the watchdog is alive
OFF when the watchdog is no longer refreshed or
dead
DS26 AC Power ON Green ON when the 220 V AC supply is okay
OFF when the 220 V AC supply is defective or not
connected
