1-87. W507 – Filter Wheel DC Motor Connect
Filter Wheel DC motor (M5) to Interconnection board (PI 2376693) M5:
1-88. W508 – Rectangular Blade Unit DC Motor Connect (Maxon)
Four cables, used to connect the rectangular blade DC motor connectors (M1 through M4) to the Inter-
connection board connectors M1 through M4 (board PI 2408939).
Connectors Mx in the table below correspond to the following:
Front blade - M1; Left blade - M2; Rear blade - M3; Right blade - M4
1-89. W509 – Filter Wheel DC Motor Connect (Maxon)
Filter Wheel DC motor (M5) to Interconnection board (PI 2408939) M5:
Designation Level Pin No.
Motor - 0/24 V M5-1
Motor + 0/24 V M5-2
GND 0 V M5-3
VCC 5 V M5-4
Channel B 0/5 V M5-5
Channel A 0/5 V M5-6
Designation Level Pin No.
Motor - 0/24 V Mx-1
Motor + 0/24 V Mx-2
GND 0 V Mx-3
VCC 5 V Mx-4
Channel B 0/5 V M5x5
Channel A 0/5 V Mx-6
Designation Level Pin No.
Motor - 0/24 V M5-1
Motor + 0/24 V M5-2
GND 0 V M5-3
VCC 5 V M5-4
Channel B 0/5 V M5-5
Channel A 0/5 V M5-6
