Job Card PHY A003 - Gantry and Control Station Installation
5 PREREQUISITES
• The procedures described in Job Card PHY A001 - Unpacking the Gantry and Generator Cabinet
on page 391 must have been completed.
• The floor positions for the bolts securing the Gantry and the Control Station must have been
agreed and marked as described in Anchoring to the Floor on page 354).
• When establishing the position for the Generator Cabinet, note that the "CE" marking label,
located on one of the large side panels of the Generator, must remain visible after installation.
6 PREPARE THE ANCHOR POSITIONS FOR GANTRY AND CONTROL
STATION
!
Notice:
For safety reasons, it is mandatory that the Gantry and the Control Station are securely bolt-
ed to the floor.
1. Before proceeding, it is recommended that you perform a final verification of the information given in
the Pre-Installation Manual. Particularly, verify clearances around the Gantry and Control Station
when installed in its permanent position.
2. Ensure that suitable provision has been made for passage of cable harnesses between the Gantry,
the Generator, and the Control Station.
Connections are already made in the Gantry and Generator.
The Control Station cable harness (set of cables in a black flexible conduit) must be routed and con-
nected after it has been installed.
A cable must be run from the Generator to connect the X-ray Console. If the X-ray Console is posi-
tioned on the Control Station, the cable can be run alongside the Control Station cable harness.
3. Drill and prepare the securing holes:
CAUTION
Check that there are no water or electrical ducts where you drill.
Refer to the under-floor plan localizing the water and electrical ducts which has been done
during the Pre-Installation.
a. Check that the seven mounting hole centers have been correctly marked.
b. Drill the mounting holes, three (five in seismic areas) for the Gantry and four for the Control Sta-
tion. Drill-bit sizes and hole depths vary according to the bolts used - see Anchoring Inserts Pro-
vided with the Senographe System (only for non-seismic areas) on page 354 and Anchoring
Inserts Not Provided with the Senographe System (for seismic areas) on page 355)).
c. Place an insert into each of the mounting holes, ready to receive one of the bolts provided.
