Chapter 6 Page no. 440
JC-PHY-A-010.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card PHY A010 - Mount LCD Monitor on Control Station
4. Remove the pre-routed monitor earth cable from the harness, and connect it to the same Earth Bar
connector accommodating the cable labelled 5166436.
5. Create a loop with the excess earth cable, and secure the loop with a cable tie (6).
6
Monitor earth cable going
down to earth bar
