Chapter 6 Page no. 528
JC-PHY-A-044.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card PHY A044 - Remove/Reinstall Gantry Covers
8-2-2 Arm Cover Reinstallation
• To reinstall the arm covers, carry out the above operations in reverse order.
Note:
During reassembly of flexible covers, be careful not to apply excessive force to the side securing
screws (11), to avoid breaking the support.
CAUTION
During reassembly of the small pulley (5), double check that its anti-rotation key (6) and
securing clip (4) are correctly set in place.
If the key is absent or the belt slides from its position, manual compression functions and
braking are not available. If there is a motorized compression failure patient injury is pos-
sible.
• After installing the Arm covers, always carry out the procedures described in Job Card ELE A017 -
Manual Compression Check and Calibration on page 583.
