GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Product history and compatibility
Note:
This matrix is extremely important to consider when you change one of the listed components.
Component CESM1
(Optional
Upgrade)
Pixel Spacing
(FMI 12166)
CESM 2
(Optional
Upgrade)
Sunburst
ADS Hardware Computer U20 or Z400 U20 or Z400 U20 or Z400 Z400
Detector Type SFOV1 or
SFOV2
SFOV1 or
SFOV2
SFOV1 or
SFOV2
SFOV1 or
SFOV2
IDC Hardware Computer Dione 5 Dione 5 Dione 5 Dione 5
ADS Software Kit 55.10 54.11 55.20 54.20
IDC Software Kit 11.10.1 10.0.5 11.10.1 10.0.5
Generator CPU Board
(DMR)
5.30 4.02 5.30 4.02
Gantry CPU Board
(Poseidon)
NSC.1.2.15 NSC.1.2.15 NSC.1.2.15 NSC.1.2.15
Interface Board FPGA 4A FPGA 4A FPGA 4A FPGA 4A
Rotation Board CPLD 5.1.2 5.1.2 5.1.2 5.1.2
DSP 5.13.5 5.13.5 5.13.5 5.13.5
HC12 5.12.4 5.12.4 5.12.4 5.12.4
Lift Board CPLD 10.0.1 10.0.1 10.0.1 10.0.1
DSP 5.6.3 5.6.3 5.6.3 5.6.3
HC12 5.16.2 5.16.2 5.16.2 5.16.2
Compression Board CPLD 5.1.4 5.1.4 5.1.4 5.1.4
HC12
5.12.1 5.12.1 5.12.1 5.12.1
Tilt Board CPLD 5.1.5 5.1.5 5.1.5 5.1.5
HC12 5.4.0 5.4.0 5.4.0 5.4.0
Collimator DSP Rev1026 Rev1026 Rev1026 Rev1026
PDU Board HC12 5.0.7 5.0.7 5.0.7 5.0.7
Bucky Board CPLD 5.0.3 5.0.3 5.0.3 5.0.3
HC12
5.4.6 5.4.6 5.4.6 5.4.6
Gantry CD-ROM to use to get
required system level
5174994-11 5174994-11 5174994-11 5174994-11
*- With the complete rollout of FMI12075, all systems in the field are at least at an IS4-3 system level.
** - Systems that received FMI12075 have NSC.1.1.7 and IS4-3 Forward Production systems will have
NSC.1.1.8. You must use Gantry CD-ROM to ensure that the Gantry CPU Board is at NSC.1.1.8.
*** - Systems that received FMI12075 may have Lift CPLD 5.0.1 and IS4-3 Forward Production systems
will have Lift CPLD 10.0.1.
**** - Systems that received FMI12075 may have PDU HC12 4.0.7 and IS4-3 Forward Production systems
will have PDU HC12 5.0.7.
***** - IDC Software 10.0.5 introduced at Penduick must only be used on the Dione 5 form factor IDC.
When changing an IDC on a pre-Penduick IB system, if no more Dione 4 IDCs exist you will receive a
Dione 5 IDC on which you must install IDC SW 10.0.5.
