ERR SUB A001 - Generator Error Messages
004/013 Gene interface: interrupt error on PTM1
timer 1
004/014 Gene interface: interrupt error on PTM1
timer 2
004/015 Gene interface: interrupt error on PTM1
timer 3
004/016 Gene interface: interrupt error on PTM2
timer 1
004/017 Gene interface: interrupt error on PTM2
timer 2
004/018 Gene interface: interrupt error on PTM2
timer 3 D208
006/000 Generator: fault at exposure command
006/001 Generator: fault at exposure command
006/002 Generator: signal kV_Inf_5
(Less_than_5kV) not rising
006/003 Generator: Signal En_Pose
(Exposure_On) not rising
006/004 Generator: fatal security triggered dur-
ing exposure
006/005 Generator: fatal security triggered at
end of exposure or signal En_Pose
(Exposure_On) stays ’high’
006/011 Generator: signal Secu_Rattrap
(No_Fatal_Security) stays ’high’ after
’arcing recovery’
006/028 E20 Check Main
Distribution Rack
The Mains Distribution Rack is not cor-
rectly powered ON. The Low Voltage
Power Supply (LVPS) output at the J6
connector is too low to supply the Main
Distribution Assembly (expected volt-
age is 12 Vdc).
Proceed as follows:
• Reboot the entire system.
• If the problem persists, check volt-
age at LVPS output J6 connector,
and adjust to 12 Vdc if required or
replace the LVPS.
• Reboot the Gantry and check no
error code displays on the X-ray
Console.
Code Message text Description Recommended actions
