ERR SUB A003 - Gantry Error Messages
Page no. 853 Chapter 9
ERR-SUB-A-003.fm
100/004 WARNING FOOTSWITCH IS
PRESSED
UIF Still Pressed [i] (for i =1 - 4) = Occurs when one
of the 2 (resp 4) buttons on footswitches are pressed
during node boot-up:
- Lift up: 0x9006
- Lift down: 0x9005
(- Compression up): 0x9008
(- Compression down): 0x9007
Right or left are not differentiated. Double Footswitch
concerns 2 error signals and quadruple footswitches
concerns 4 error signals
See JC DIAG A1001 FOOTSWITCH IS PRESSED
on page 945 to fix the problem.
A1001
page 945
100/005 WARNING FOOTSWITCH IS
PRESSED
100/006 WARNING FOOTSWITCH IS
PRESSED
100/007 WARNING FOOTSWITCH IS
PRESSED
100/009 HALT LIFT POSITION
ERROR
The Lift is over the upper software limit. Occurs
when the lift position is not between the software lim-
its at power-up (including a tolerance to be defined).
Typically, this can happen when the lift has been
moved manually.
Remove the Gantry covers; check the lift position. If
lift position locked into upper position, or close to the
upper position, move the lift down manually. To do
this, turn the lift screw to about 2 cm below the upper
optical fork.
100/010 HALT LIFT POSITION
ERROR
The Lift is below the lower software limit. Occurs
when the lift position is not between the software lim-
its at power-up (including a tolerance to be defined).
Typically, this can happen when the lift has been
moved manually.
Remove the Gantry covers; check the lift position. If
the lift position locked into lower position, or close to
the lower position, move the lift up manually. To do
this, turn the lift screw to about 2 cm below the upper
optical fork.
100/011 WARNING GANTRY DISPLAY
FAILURE
The LCD has failed.
Faulty FRU = LCD
Reboot the system from the X-ray Console. If the
problem persists, change the LCD.
100/013 N/A RELAY DEFECT When the node moves to operational state it checks
if the relay state is according to the board safety
state (for example missing STOP_MOTION_LINE
has to disable the relay). This error is triggered,
when there are no safety problems on the board, but,
for some reason, the relay doesn't allow motion.
Probable root cause: Broken or stucked relay
The board shall be changed.
