GE Senographe DS

Chapter 9 Page no. 872
ERR-SUB-A-003.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
ERR SUB A003 - Gantry Error Messages
112/030 WARNING ROTATION DECEL-
ERATION ERROR
The rotation motion began to slow down but did not
stop before the allowed time.
Refer to JC DIAG A1115 ROTATION POSITION
OVERSHOOT/ROTATION CONTROL FAILURE on
page 954 to fix the problem.
A1115
page 954
112/031 HALT ROTATION
MOTION STARTED
IN REVERSE
DIRECTION
The rotation motion was about to go in the reverse
direction to the direction that was requested.
Change the Rotation board then perform a Rotation
Calibration.
D/R A221
page
1223
CAL 021
page
1679
112/032 HALT ROTATION DSP
TIMEOUT
The DSP did not answer to the MCU before the time-
out.
Change the Rotation board then perform a Rotation
Calibration.
D/R A221
page
1223
CAL 021
page
1679
112/033 WARNING ROTATION CAN
COMMAND NOT
PROCESSED
The CAN command was not processed. The main
CPU have sent command to the rotation node before
the rotation node could acknowledge the previous
command.
Reboot the system from the X-ray Console.
Retry the command.
If the problem persists, contact your OLC.
112/034 HALT ROTATION RX CAN
BUFFER OVERRUN
Possible causes:
• CAN overrun. The input queue of the incoming
CAN messages of the MCU is full and message
dropped.
• The TP1 connector on the Rotation board is
closed.
Proceed as follows:
Check whether a jumper exists on the TP1 connector
on the Rotation board. In this case you must remove
the jumper from the TP1 connector on the Rotation
board.
If there is no jumper on the TP1 connector on the
Rotation board, reboot the complete system. If the
problem persists, check the other nodes (other than
rotation). If the other nodes are OK, check the rota-
tion node (cabling, potentiometer, board).
Code Category Text in Log File or
on LCD
Possible Cause/Recommended Action Job Card
