GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
ERR SUB A003 - Gantry Error Messages
Page no. 873 Chapter 9
ERR-SUB-A-003.fm
112/035 HALT ROTATION TX CAN
BUFFER OVERRUN
The transmit queue between the MCU and the DSP
is full and message dropped.
Change the Rotation board then perform a Rotation
Calibration.
D/R A221
page
1223
CAL 021
page
1679
112/036 HALT ROTATION MAIL-
BOX OVERRUN
The mailbox queue used in the inter-task communi-
cation in the MCU is full and mails dropped.
Change the Rotation board then perform a Rotation
Calibration.
D/R A221
page
1223
CAL 021
page
1679
112/037 HALT CPU HEARTBEAT
NOT RECEIVED BY
ROTATION NODE
There has been a heartbeat failure. The Gantry CPU
did not send periodic "heartbeat" CAN message.
1. Change the Gantry CPU Board (see Job Card D/
R A190 - Gantry CPU Board on page 1131).
2. Perform a Collimator Calibration (see Job Card
CAL A029 - Collimator Format Calibration on
page 1683).
3. Perform a Collimation Check (see Job Card ELE
A028 - Collimation Checks on page 679).
D/R A190
page
1131
CAL A029
page
1683
ELE A028
page 679
112/038 DEBUG
ONLY
HEARTBEAT DIS-
ABLED ON ROTA-
TION NODE
The Gantry CPU tried to disable the "heartbeat"
check of the rotation node.
1. Change the Gantry CPU Board (see Job Card D/
R A190 - Gantry CPU Board on page 1131).
2. Perform a Collimator Calibration (see Job Card
CAL A029 - Collimator Format Calibration on
page 1683).
3. Perform a Collimation Check (see Job Card ELE
A028 - Collimation Checks on page 679).
D/R A190
page
1131
CAL A029
page
1683
ELE A028
page 679
112/039 HALT ROTATION INVALID
PDO LENGTH
The rotation node receives a PDO with an invalid
DLC.
Refer to JC DIAG A1117 ROTATION COMMUNICA-
TION FAILURE on page 955 to fix the problem.
A1117
page 955
Code Category Text in Log File or
on LCD
Possible Cause/Recommended Action Job Card
To Next Page
