Chapter 9 Page no. 892
ERR-SUB-A-003.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
ERR SUB A003 - Gantry Error Messages
3-4 Error Codes from 130/yyy: Tube Tilt
Code Category Text in Log File or
on LCD
Possible Cause/Recommended Action Job Card
130/001 WARNING UIF Still pressed UIF Still Pressed [i] (for i =1 - 9) = Occurs when one
of the nine buttons on the Compression Arm or Tube
Head is still pressed:
- Lift up (V1, V2)
- Lift down (V1, V2)
- Rotation Right (V1, V2)
- Rotation Left (V1, V2)
- Light/Field Of View
[i] indicates the nature of the button. Right or left is
not indicated.
Refer to JC DIAG A1301 CONTROL KEYPAD FAIL-
URE on page 963 to fix the problem.
A1301
page 963
130/002 WARNING UIF Still pressed
130/003 WARNING UIF Still pressed
130/004 WARNING UIF Still pressed
130/005 WARNING UIF Still pressed
130/006 WARNING UIF Still pressed
130/007 WARNING UIF Still pressed
130/008 WARNING UIF Still pressed
130/011 WARNING UIF Still pressed
130/012 WARNING UIF Still pressed
130/013 WARNING UIF Still pressed
130/014 WARNING UIF Still pressed
130/010 INHIBIT Tube Tilt initializa-
tion failure
At power-up, in case the optical fork is shut or not,
the Tube Tilt moves in one direction or the other in
order to find the transition. After the transition has
been found, the Tube Tilt goes up and down for a
definite number of steps. The Tube Tilt board checks
that the transition is reached after the good number
of steps. If this series of Tube Tilt events does not
occur, this error is produced.
Refer to JC DIAG A1302 TUBE HEAD CONTROL
FAILURE on page 965 and to Job Card D/R A292 -
Tube Tilt Pivots on page 1397 to fix the problem.
A1302
page 965
D/R A292
page
1397
131/001 INHIBIT Tube Tilt software
error
The software/firmware on the Tube Tilt board is cor-
rupt.
Change the Tilt board then perform a Tilt Calibration.
D/R A266
page
1365
CAL A027
page
1681
131/002 INHIBIT Tube Tilt software
error
The software/firmware on the Tube Tilt board is cor-
rupt.
Change the Tilt board then perform a Tilt Calibration.
D/R A266
page
1365
CAL A027
page
1681
131/003 INHIBIT Tube Tilt calib not
achieved
The Tube Tilt board has not been calibrated or has
lost the current calibration settings.
Perform a Tilt Calibration.
CAL A027
page
1681
To Next Page
