GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
ERR SUB A003 - Gantry Error Messages
Page no. 893 Chapter 9
ERR-SUB-A-003.fm
132/000 INHIBIT TILT INVALID PDO
LENGTH
Change the Tilt board then perform a Tilt Calibration. D/R A266
page
1365
CAL A027
page
1681
132/001 INHIBIT Tube Tilt software
error
The software/firmware on the Tube Tilt board is cor-
rupt.
This failure is linked to a firmware problem (micro-
controller or CPLD). Change the Tilt board then per-
form a Tilt Calibration.
D/R A266
page
1365
CAL A027
page
1681
132/002 WARNING Tube Tilt fan error The rotation speed of the FAN is monitored through
a third wire. If it is not within an acceptable range,
this signal is produced
Change the Fan and cable W406.
132/003 HALT Tube Tilt switch
defect
SwitchDefect [i] (for i = 1 - 9) occurs when the two
signals from the button do not arrive at the same
time on the CPLD.
The error signal indicates the nature of the button but
not the side right or left.
- Lift up (V1, V2)
- Lift down (V1, V2)
- Rotation Right (V1, V2)
- Rotation Left (V1, V2)
- Light/Field Of View
- MLO +/-
- CC
Refer to JC DIAG A1301 CONTROL KEYPAD FAIL-
URE on page 963 to fix the problem.
A1301
page 963
132/004 HALT Tube Tilt switch
defect
132/005 HALT Tube Tilt switch
defect
132/006 HALT Tube Tilt switch
defect
132/007 HALT Tube Tilt switch
defect
132/008 HALT Tube Tilt switch
defect
132/009 HALT Tube Tilt switch
defect
132/010 HALT Tube Tilt switch
defect
132/025 HALT Tube Tilt switch
defect
132/026 HALT Tube Tilt switch
defect
132/027 HALT Tube Tilt switch
defect
Code Category Text in Log File or
on LCD
Possible Cause/Recommended Action Job Card
