ERR SUB A003 - Gantry Error Messages
132/012 INHIBIT Tube Tilt step lost After the transition has been found, the Tube Tilt
goes up and down for a definite number of steps.
The Tube Tilt board checks that the transition is
reached after the good number of steps. If not, this
error signal is produced.
Refer to JC DIAG A1302 TUBE HEAD CONTROL
FAILURE on page 965 and to Job Card D/R A292 -
Tube Tilt Pivots on page 1397 to fix the problem.
A1302
page 965
D/R A292
page
1397
132/013 INHIBIT TILT NODE FW
INCOMPATIBILITY
Occurs when the hardware configuration (CPLD) of
the node or the DSP or the MCU firmware not match.
Change the Tilt board then perform a Tilt Calibration.
D/R A266
page
1365
CAL A027
page
1681
132/014 INHIBIT TILT NODE PARITY
ERROR
Occurs when the parity bit does not set correctly on
the on-board bus between the CPLD and the MCU.
Change the Tilt board then perform a Tilt Calibration.
D/R A266
page
1365
CAL A027
page
1681
132/015 INHIBIT LOW VOLTAGE
ERROR ON TILT
NODE
Occurs if the voltage of the power supply to the Tube
Tilt board falls below 24 V.
Change the Tilt board then perform a Tilt Calibration.
D/R A266
page
1365
CAL A027
page
1681
132/016 INHIBIT TILT READ TIME-
OUT ERROR
Occurs if the MCU does not react within 15 ms of
receiving an interrupt request (IRQ) coming from the
CPLD.
Change the Tilt board then perform a Tilt Calibration.
D/R A266
page
1365
CAL A027
page
1681
132/017 INHIBIT TILT CPLD MEM-
ORY ERROR
Test data from the CPLD is periodically read to
ensure the proper communication. This error occurs
if this data from the CPLD does not match.
Change the Tilt board then perform a Tilt Calibration.
D/R A266
page
1365
CAL A027
page
1681
