GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
ERR SUB A003 - Gantry Error Messages
Page no. 895 Chapter 9
ERR-SUB-A-003.fm
132/018 INHIBIT TILT COMMAND
SEQUENCE IS
INCORRECT
The checksum on the calibration data stored by the
MCU does not match.
Change the Tilt board then perform a Tilt Calibration.
D/R A266
page
1365
CAL A027
page
1681
132/019 INHIBIT TILT MCU CALI-
BRATION DATA
CORRUPT
The checksum on the calibration data stored by the
MCU does not match.
Perform the tube tilt calibration, if the problem per-
sists, change the tube tilt board.
CAL A027
page
1681
D/R A266
page
1365
132/020 INHIBIT TILT MCU EEPROM
FAILURE
The readback on the newly written data to the
EEPROM failed.
Change the Tilt board then perform a Tilt Calibration.
D/R A266
page
1365
CAL A027
page
1681
132/021 INHIBIT TILT CAN COM-
MAND NOT PRO-
CESSED
The CAN command was not processed. The Gantry
CPU has sent command to the compression node
before the compression node could acknowledge the
previous command.
1. Change the Gantry CPU Board (see Job Card D/
R A190 - Gantry CPU Board on page 1131).
2. Perform a Collimator Calibration (see Job Card
CAL A029 - Collimator Format Calibration on
page 1683).
3. Perform a Collimation Check (see Job Card ELE
A028 - Collimation Checks on page 679).
D/R A190
page
1131
CAL A029
page
1683
ELE A028
page 679
132/022 INHIBIT TILT CAN BUFFER
OVERRUN
The input queue of the incoming CAN messages of
the MCU is full and message dropped.
Reboot the complete system. If the problem persists,
check the other nodes (not tube tilt). If other nodes
are good, check the tube tilt node (cabling, board).
132/023 INHIBIT TILT MAILBOX
OVERRUN
The mailbox queue used in the inter-task communi-
cation in the MCU is full and mails dropped.
Change the Tilt board then perform a Tilt Calibration.
D/R A266
page
1365
CAL A027
page
1681
Code Category Text in Log File or
on LCD
Possible Cause/Recommended Action Job Card
