Chapter 9 Page no. 896
ERR-SUB-A-003.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
ERR SUB A003 - Gantry Error Messages
132/028 INHIBIT Tilt overcurrent A motion over current is detected.
Refer to JC DIAG A1305 TILT CONTROL FAILURE
on page 966 and to Job Card D/R A292 - Tube Tilt
Pivots on page 1397 to fix the problem.
A1305
page 966
D/R A292
page
1397
132/029 INHIBIT CPU HEARTBEAT
NOT RECEIVED BY
TILT NODE
A heartbeat failure occurred. The Gantry CPU did
not send periodic "heartbeat" CAN message.
1. Change the Gantry CPU Board (see Job Card D/
R A190 - Gantry CPU Board on page 1131).
2. Perform a Collimator Calibration (see Job Card
CAL A029 - Collimator Format Calibration on
page 1683).
3. Perform a Collimation Check (see Job Card ELE
A028 - Collimation Checks on page 679).
D/R A190
page
1131
CAL A029
page
1683
ELE A028
page 679
132/024 DEBUG
ONLY
HEARTBEAT
DISABLED ON TILT
NODE
The Gantry CPU tried to disable the "heartbeat"
check of the tilt node.
1. Change the Gantry CPU Board (see Job Card D/
R A190 - Gantry CPU Board on page 1131).
2. Perform a Collimator Calibration (see Job Card
CAL A029 - Collimator Format Calibration on
page 1683).
3. Perform a Collimation Check (see Job Card ELE
A028 - Collimation Checks on page 679).
D/R A190
page
1131
CAL A029
page
1683
ELE A028
page 679
132/030 DEBUG
ONLY
TILT INVALID
RX_OPTICAL_FOR
K1_ERROR
Ignore this error. If the problem persists, contact your
OLC.
132/031 DEBUG
ONLY
TILT INVALID
RX_OPTICAL_FOR
K2_ERROR
Ignore this error. If the problem persists, contact your
OLC.
132/032 DEBUG
ONLY
TILT INVALID
LIFT_DOWN_PEDA
L_ERROR
Ignore this error. If the problem persists, contact your
OLC.
132/033 DEBUG
ONLY
TILT INVALID
LIFT_UP_PEDAL_E
RROR
Ignore this error. If the problem persists, contact your
OLC.
132/034 DEBUG
ONLY
TILT INVALID
COMPRESSION_PE
DAL_ERROR
Ignore this error. If the problem persists, contact your
OLC.
132/035 DEBUG
ONLY
TILT INVALID
DECOMPRESSION
_PEDAL_ERROR
Ignore this error. If the problem persists, contact your
OLC.
132/036 DEBUG
ONLY
TILT INVALID
STOP_MOTION_MC
U_ACTIVE ERROR
Ignore this error. If the problem persists, contact your
OLC.
Code Category Text in Log File or
on LCD
Possible Cause/Recommended Action Job Card
