Chapter 9 Page no. 902
ERR-SUB-A-003.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
ERR SUB A003 - Gantry Error Messages
141/006 INHIBIT Coll out of FOV
(front)
Invalid parameter for axis[i] (for i=1 - 5) = collimator
control board received a command for axis[i] that has
an invalid parameter. Either a wrong FOV value or a
wrong filter type.
Possible causes of error:
- Collimator has received bad data on its node
- Communication conflict/mismatch between
system and collimator
Actions to correct problem:
1. Check the cable connection (W409) between the
collimator and system, then restart system from
the X-ray Console.
2. If the problem persists, change the CPU board
(re-calibrate the collimator afterwards).
3. If the problem persists, contact your OLC.
D/R A190
page
1131
CAL A029
page
1683
141/007 INHIBIT Coll out of FOV (left)
141/008 INHIBIT Coll out of FOV(rear)
141/009 INHIBIT Coll out of FOV
(right)
141/010 INHIBIT Coll filter type not
exist
141/011 INHIBIT Coll beyond phy limit
(front)
axis[i](for i=1 - 4) beyond physical limit = the FOV is
beyond the blade capability.
1. Re-perform the collimator calibration. If the prob-
lem persists, identify the type of collimator cur-
rently in your system.
2. Replace the Collimator Set (refer to Job Card D/
R A280 - Collimator Set on page 1369).
3. Perform Collimator Format Calibration.
D/R A280
page
1369
CAL A029
page
1683
141/012 INHIBIT Coll beyond phy limit
(left)
141/013 INHIBIT Coll beyond phy limit
(rear)
141/014 INHIBIT Coll beyond phy limit
(right)
Code Category Text in Log File or
on LCD
Possible Cause/Recommended Action Job Card
