GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card DIAG A1000 - Gantry Diagnostic
Page no. 975 Chapter 9
JC-DIAG-A-1000.fm
2-50 JC DIAG A1504 LOW POWER 2 FUSE IS BAD
Diagnostic for:
152/026 error code (CAN code is 0x5000) Fuse LP2 error
• Inspect the F1 fuse on the PL101 PDU Board. If it is good, change the PDU Board (see Job Card D/
R A191 - PDU Board on page 1137).
FRUs:
2-51 JC DIAG A1505 HIGH POWER FUSE IS BAD
Diagnostic for:
152/027 error code (CAN code is 0x5001) Fuse HP error
• Inspect the F1 (20 A fuse) on the MPCB Terminal Block ST102. If it is good, change the PDU Board
(see Job Card D/R A191 - PDU Board on page 1137).
FRUs:
2-52 JC DIAG A1506 LOW POWER 1 FUSE IS BAD
Diagnostic for:
152/028 error code (CAN code is 0x5002) Fuse LP1 error
• Inspect the F3 fuse on the PL101 PDU Board. If it is good, change the PDU Board (see Job Card D/
R A191 - PDU Board on page 1137).
FRUs:
2-53 JC DIAG A1507 MAIN CPU FUSE IS BAD
Diagnostic for:
152/029 error code (CAN code is 0x5003) Fuse CPU error
• Inspect the F4 fuse on the PDU Board. If it is good, change the PDU Board (see Job Card D/R A191
- PDU Board on page 1137).
FRUs:
F1 Fuse
PDU Board
Fuse 20 A
PDU Board
F3 Fuse
PDU Board
F4 Fuse
PDU Board
