3-36 Section 3-7 - Printer Installation
Section 3-7
Printer Installation
NOTE: For Connection schemes refer to Section 3-5 "Connection of Auxiliary Devices" on page 3-9.
For further installation instructions see:
• Section 3-7-1 "Installing Digital Black & White Printer" on page 3-36
• Section 3-7-2 "Installing Digital Color Printer" on page 3-36
• Section 3-7-3 "Printer Installation manually" on page 3-37
• Section 3-7-4 "Adjustment of Printer Settings" on page 3-41
3-7-1 Installing Digital Black & White Printer
1.) Power off/Shutdown the system as described in: Section 3-6-3 on page 3-34.
2.) Connect and install the printer as described on page 3-11.
3-7-2 Installing Digital Color Printer
1.) Power off/Shutdown the system as described in: Section 3-6-3 on page 3-34.
2.) Connect and install the printer as described on page 3-13.
!! CAUTION:
The Bluetooth Printer Connection set as well as the Color Deskjet printer MUST NOT be installed
by the user!
For installation please contact your local distributor or GE service representative.
!! NOTICE:
After boot up of the system, verify the correct settings in the printer “Properties”,
see: Section 3-7-4 "Adjustment of Printer Settings" on page 3-41.
Afterwards assign the Printer to the remote keys P1
, P2, P3 and/or P4,
see: Section 3-7-5 "Remote Control Selection" on page 3-48.
!! NOTICE:
After boot up of the system, verify the correct settings in the printer “Properties”,
see: Section 3-7-4 "Adjustment of Printer Settings" on page 3-41.
Afterwards assign the Printer to the remote keys P1
, P2, P3 and/or P4,
see: Section 3-7-5 "Remote Control Selection" on page 3-48.
