GE HEALTHCAREDRAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
Chapter 5 - Components and Functions (Theory) 5-27
5-3-2 RTM - Beamformer Motherboard
Connects Transmitter- and Receiver Subboards
The RTM Beamformer Motherboard contains:
• 16 (8) pcs. of RSR (see: Section 5-3-3 "RSR- Beamformer Receiver Subboards" on page 5-28)
• 16 (12) pcs. of RST (see: Section 5-3-4 "RST- Beamformer Transmitter Subboards" on page 5-28)
• 1 (optional) RSW (see: Section 5-3-5 "RSW - CW-Doppler Board (optional)" on page 5-29)
!! NOTICE:
16 pieces of RSR and 16 pieces of RST at Voluson E8.
8 pieces of RSR and 16 pieces of RST at Voluson E6 (BT09).
8 pieces of RST and 12 pieces of RST at Voluson E6 (BT10/BT12/BT13).
