GE Voluson E6

GE HEALTHCARERAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
3-58 Section 3-9 - Available Probes
3-8-4-1 External I/O Pin Outs (cont’d)
3-8-5 Video Specification
Video specifications may be needed to be able to connect laser cameras or other devices to the Voluson
E8 / Voluson E6.
DVI-D/VGA-Connector:
- Visible resolution ... 1024x768
- Screen refresh rate ... 60Hz
S-Video Connector:
- Type: Separate Video (Y/C)
- Video modes: PAL (50Hz), NTSC (60Hz)
Section 3-9
Available Probes
See Chapter 9 - Probes, on page 9-39, for part numbers to be used when ordering new or replacement
service probes.
Section 3-10
Software/Option Configuration
For description refer to:
• Section 3-8-1 "System Setup" on page 3-49 and
• Section 3-8-2 "Measure Setup" on page 3-53
Table 3-16 DVI-D OUT Connector
Pin No Description Pin No Description
1
TDMS data 2- 13 TDMS data 3+
2
TDMS data 2+ 14 +5 Volt
3
TDMS data 2, 4 shielding 15 ground for +5 Volt
4
TDMS data 4- 16 Hotplug-Detect
5
TDMS data 4+ 17 TDMS data 0-
6
DDC clock 18 TDMS data 0+
7
DDC data 19 TDMS data 0, 5 shielding
8
Analog: V-Sync 20 TDMS data 5-
9
TDMS data 1- 21 TDMS data 5+
10
TDMS data 1+ 22 TDMS meter shielding
11
TMDS data 1, 3 shielding 23 TDMS clock +
12
TDMS data 3- 24 TDMS clock -
NOTICE
!! NOTICE:
More detailed information pertaining System Setup and Measure Setup adjustments is found in the
Voluson E8 / Voluson E6 Basic User Manual, which is available in different languages.
