GE HEALTHCARERAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
3-14 Section 3-5 - Connection of Auxiliary Devices
3-5-3-1 Connection Scheme: Color Printer
Figure 3-7 Color Printer connection
text
DVI Out
PC
USB5 USB6
LAN
Console back
DVD Writer
I
O
RS-
232
Out
USB3
Audio
USB4
DVI - In
Monitor
UI-Top
ECG
S - Video
Out InOut
DVI - Out
Mic
Line
Out
In
USB
UI
USB Hub
Top
to USB4
A
BC
DE
Lift
Aux
Lift is only used for the lifter
(230V - can not be changed)
Color Printer
(e.g., Sony UP-D25MD)
To Next Page
