Chapter 10 - Care & Maintenance 10-25
Section 10-9
Ultrasound Equipment Quality Check (EQC)
.
GE Healthcare
Ultrasound Equipment Quality Check (EQC)
Customer Name: System ID: Model No.: Upgrade Model: Date Performed:
Dispatch No.: System Type: Serial No.: Upgrade Serial No.: Software Level:
Test Equipment Serial No.: Calibration Due Date:
10-5-1 PRELIMINARY CHECKS 10-5-3 CLEANING
Item Complete Comments Item Complete Comments
Ask/Listen Console
Labeling Op Panel
Power Up Monitor (CRT/LCD)
InSite Touch screen
Review Error Logs Probe Holder
Diagnostics (Optional) Filter
Preset Backup
10-5-2 PHYSICAL INSPECTION 10-5-4 FUNCTIONAL CHECKS
Item
Complete Comments
Item Complete Comments
Input Power Monitor
External I/O Touch Panel
Wheels and Brakes Keyboard
Control Panel Movement B-Mode
Cables and Connectors M-Mode
Shielding and Covers CF-Mode
Console Doppler Modes
Control Panel Peripherals
10-7 ELECTRICAL SAFETY 10-5-5 and 10-7 PROBES
Tests Performed Max Value
Probe
Name
Model No. Serial No.
Leakage Gnd
Closed
Leakage Gnd
Open
Visual Functional
Probe Care
Assessment
Ground Continuity
ohms
μA μA
ohms
Chassis Leakage
μA
μA μA
μA
ECG Lead to Ground
μA μA μA
ECG Lead to Lead
μA μA μA
ECG ISO
μA μA μA
μA μA
Comments:
Performed By: _______________________________________________________________________________________________________
©2009 General Electric Company.
GE and GE Monogram are trademarks of General Electric Company.
General Electric Company, doing business as GE Healthcare.
DOC0537351, Rev. 2
Reset
Save
