GE HEALTHCAREDRAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
Chapter 3 - Setup Instructions 3-37
3-7-3 Printer Installation manually
1.) Press the UTILITIES key on the control panel.
2.) In the “Utilities” menu touch SYSTEM SETUP
to invoke the setup desktop on the screen.
3.) On the left side of the screen select CONNECTIVITY
and then click on the PERIPHERALS tab.
4.) Click the ADD PRINTER
button (see: Figure 3-32 above).
Please read the displayed message carefully and click YES
if you have skills to do this.
5.) Click the NEXT
button to start the Add Printer Wizard.
6.) Select the ‘Local Printer‘, deselect “Automatically install Plug and Play printer” and then click NEXT
.
Figure 3-32 System Setup - Connectivity - PERIPHERALS page
Figure 3-33 Add Printer Wizard
[Add Printer]
button
Foot Switch
Remote Control
Report Printer
selection
To Next Page
