The Voluson E8 / Voluson E6 ultrasound system comes equipped with product labels and icons.
These labels and icons represent pertinent information regarding the operation of the system.
1-3-6-1 Identification and Rating Plate
The Identification and Rating Plate is located on the rear of the Voluson E8 / Voluson E6 system.
BT Version:
BT-Version:
Product labels and its location depend on BT-version and/or date of manufacture.
Refer to Section 1-2-3 on page 1-8 and Chapter 2 in the Basic User Manual of your system.
BT Version:
BT-Version:
The layout of the Identification and Rating Plate depends on BT-version and/or date of manufacture.
Figure 1-2 Identification and Rating Plate: Examples
1 Manufacturer 5 System Serial Number 9 WEEE Disposal icon
2 Model Type 6 Manufacturing date 10 TUEV NRTL Certification mark
3 System Voltage range 7 Frequency 11 CE Conformity mark
4 Power Consumption nominal 8 Safety type: Type BF 12 FDA Guidance
13 Hg label
14 approx. weight of the system
15 GOST-R label
* * * *
* * * *
