1-8 Section 1-2 - Important Conventions
1-2-2 Standard Hazard Icons
Important information will always be preceded by the exclamation point contained within
a triangle, as seen throughout this chapter. In addition to text, several different graphical
icons (symbols) may be used to make you aware of specific types of hazards that could
cause harm. Even if a symbol isn’t used in this manual, it is included for your reference.
Other hazard icons make you aware of specific procedures that should be followed.
1-2-3 Product Labels and Icons
The following table describes the purpose and location of labels, safety icons and other important
information provided on the equipment.
Table 1-4 Standard Hazard Icons
ELECTRICAL MECHANICAL RADIATION LASER HEAT PINCH
Table 1-5 Standard Icons Indicating a Special Procedure be Used
AVOID STATIC ELECTRICITY TAG AND LOCK OUT WEAR EYE PROTECTION
WEAR HAND PROTECTION WEAR FOOT PROTECTION
BT-Version:
Product labels and its location depend on BT-version and/or date of manufacture. For description of all
symbols and labels used on the system, refer to Chapter 2 in the Basic User Manual of your system.
Table 1-6 Product Labels and Icons
LABEL/SYMBOL PURPOSE/MEANING LOCATION
Identification and
Rating Plate
Manufacturer's name and address
Model and serial numbers
Electrical ratings
rear side of system
on each probe
