Chapter 9 - Renewal Parts 9-3
Section 9-3
Parts List Groups
Figure 9-1 Console Views
Table 9-1 Mechanical and user accessible parts
Item Part Group Name Table Number Description
100-
Housing - Mechanical Hardware Parts & Covers
• Housing - Mechanical Hardware Parts & Covers cont´d
Table 9-2 on page 9-4
Table 9-3 on page 9-5
Housing Covers (except UI and Monitor),
Caster Wheels, Handle
200-
User Interface
• User Interface cont´d
Table 9-4 on page 9-7
Table 9-5 on page 9-8
Console (keyboard, trackball, display, special
knobs and switches) Loudspeakers, Disk Drive,
Probe holder, Console Covers, etc.
300-
Monitor + Monitor Replacement Parts
Table 9-7 on page 9-11 Monitor + Monitor replacement parts
400-
Main Power Modules
Table 9-8 on page 9-12 Primary and Secondary Power Supply Modules
500-
550-
Main Board Module
• FrontEnd (US-Part) Components
• FrontEnd (US-Part) Components cont´d
• BackEnd (PC-Part) Components
Table 9-9 on page 9-13
Table 9-10 on page 9-15
Table 9-11 on page 9-17
Ultrasound (FrontEnd) Components
Ultrasound (FrontEnd) Components cont´d
PC-Part (BackEnd) Components
600-
Options and Upgrades
Table 9-12 on page 9-18 Software Options and Upgrades
700-
Miscellaneous Cables
Table 9-13 on page 9-21
800-
810-
820-
830-
Optional Peripherals and Accessories
• Recording Tools
• Printers
• Drives & additional Devices
• Optional Equipment
Table 9-14 on page 9-30
Table 9-15 on page 9-31
Table 9-16 on page 9-32
Table 9-17 on page 9-34
DVD recorder
B/W Printer, Color Printer, DeskJet Printer
USB Stick, HDD Drive, WLAN, etc.
Secondary Patient Monitor, etc.
System Manuals
900-
910-
920-
930-
940-
Probes
• 2D curved array Transducers
• 2D linear array Transducers
• 2D phased array Transducers
• Real-Time 4D Volume Probes
• CW-Pencil Probes
Table 9-22 on page 9-40
Table 9-23 on page 9-41
Table 9-24 on page 9-42
Table 9-25 on page 9-44
Table 9-26 on page 9-45
950
Biopsy Needle Guides
Table 9-27 on page 9-46
