GE HEALTHCAREDRAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
Chapter 10 - Care & Maintenance 10-5
Section 10-4
Tools Required
10-4-1 Special Tools, Supplies and Equipment used for Maintenance
Table 10-2 Overview of Requirements for Care & Maintenance
Tool Part Number Comments
Digital Volt Meter (DVM)
minimum 5% accuracy, 3.5 digit and 200 Ohm range required
Anti Static Kit
46–194427P231
46–194427P279
46–194427P369
46–194427P373
46–194427P370
Kit includes anti–static mat, wrist strap and cables for 200 to 240
V system
3M #2204 Large adjustable wrist strap
3M #2214 Small adjustable wrist strap
3M #3051 conductive ground cord
Anti Static Vacuum Cleaner
46–194427P278
46–194427P279
120V
230V
QIQ Phantom E8370RB
RMI Grayscale Target Model 403GS
NOTE! The use of a Phantom is not required during Preventive
Maintenance. Customer may use it as part of their Quality
Assurance Program tests.
CD-RW Media
(minimum quad speed)
DVD+RW Disc Media blank
blank 4,7GB DVD+RW disc
B/W Printer Cleaning Sheet
see printer user manual for requirements
Color Printer Cleaning Sheet
see printer user manual for requirements
Disposable Gloves
