Chapter 7 - Diagnostics/Troubleshooting 7-3
Section 7-2 Collect Vital System Information (cont’d)
Depending on systems BT-/SW-version, the display of the “System Info” page may be slightly different.
Figure 7-1 System Setup - Administration - SYSTEM INFO page (e.g., BT13)
Serial number
Application Software
Backup File Name
System Type
Date of Factory Settings
Hardware ID
(e.g., ADVANTECH ATX)
Tune version
Mainboard Type
Hardware configuration
(board versions)
button to start Hardware
configuration detection
Move the scroll bars downwards to view additional information about installed software/hardware.
Console version
(e.g., Whanam)
DVR version
show DVR version
