GE HEALTHCARERAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
7-2 Section 7-2 - Collect Vital System Information
Section 7-2
Collect Vital System Information
1.) Press the UTILITIES key on the control panel.
2.) In the “Utilities” menu touch SYSTEM SETUP
to invoke the setup desktop on the screen.
3.) On the left side of the screen select ADMINISTRATION
and then click the SYSTEM INFO tab.
The following information is necessary in order to properly analyze data or images being reported as a
malfunction or being returned to the manufacturer:
• System Type
• System Serial number (also visible on label on the back of the system)
• Application Software version
• Backup Version (File Name, Date of Factory Settings, Tune version, etc.)
• additional information (e.g., Hardware ID, “Mainboard Type”, HW configuration, etc.)
NOTE: All the above information can be found in the System Info page; see: Figure 7-1 on page 7-3.
