Chapter 7 - Diagnostics/Troubleshooting 7-27
7-8-6 DVD/CD-Drive resp. DVR-Drive Tests
7-8-6-1 Export images from “Local Archive” to DVD/CD+R/RW
1.) Insert an empty DVD/CD+R/RW into the Drive. At a DVR-Drive use a DVD+RW only!
2.) Enter “Patient Archive” by pressing the PATIENT ID
key on the control panel.
3.) On the left side of the screen select ARCHIVE
as shown in Figure 7-29 ABOVE.
4.) If not already selected, choose “Local Archive” from the “Source” pop-up menu.
5.) Select an Exam (with images).
The internal DVR-Drive is only applicable at BT12/BT13 systems.
The DVD-Drive is only able to read and write on DVD+RW (ReWriteable) media!
Please check on your DVD case before using.
Figure 7-29 Patient Archive - ARCHIVE
[Archive]
select Exam
choose “Source”
(with images)
To Next Page
