GE HEALTHCARERAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
3-62 Section 3-11 - Connectivity Setup
3-11-2 Wireless Network Configuration
1.) Connect the Wireless Network adapter as described in Section 3-5-6 on page 3-22.
2.) Press the UTILITIES
key on the control panel and touch SYSTEM SETUP to invoke setup desktop.
3.) On the left side of the screen select CONNECTIVITY
and then click the DEVICE SETUP tab.
4.) Click the WLAN CONFIGURATION
button.
!! NOTICE:
To configure the Voluson E8 / Voluson E6 ultrasound system to work with WLAN, the hospital’s
network administrator has to provide the required information.
Figure 3-58 WLAN Configuration button
[WLAN Configuration]
button
To Next Page
