3-66 Section 3-12 - Network IP Address Configuration
3-12-1 Map Network Drive
1.) Press the UTILITIES key on the control panel.
2.) In the “Utilities” menu touch SYSTEM SETUP
to invoke the setup desktop on the screen.
3.) On the left side of the screen select CONNECTIVITY
and then click the DRIVES tab.
4.) Select the MAP NETWORK DRIVE
button to open a dialog where the system can be connected to
a shared network drive of another server.
5.) Enter the name of the shared network folder in the „Network Folder Name” field.
6.) Supply a valid user name and a password for this folder.
NOTE: If you check the „Automatic Reconnect“ box, the system tries to establish the connection
again when starting up.
Otherwise, the connection must be re-established manually after a shutdown or reboot.
Figure 3-64 System Setup - Connectivity - DRIVES page
Figure 3-65 Map Network Drive window
!! NOTICE:
The MAP NETWORK DRIVE button is also accessible in the “Connect USB and Network Drives” dialog
window that appears when pressing the USB
(= F5) key on the alphanumeric keyboard.
[Map Network Drive]
button
