Chapter 3 - Setup Instructions 3-57
3-8-4-1 External I/O Pin Outs (cont’d)
Table 3-12 Network Connector, RJ45 Modular 8 Pin
Pin No Output Signal Description
1 ETHER TD Ethernet RD+
2 ETHER TD Ethernet RD-
3 ETHER RD Ethernet TD+
6 ETHER RD Ethernet TD-
Others NC No connection
Table 3-13 USB Connectors
Pin No Output Signal Description
1 VCC USB Power Supply
2 - Data USB Data (-)
3 + Data USB Data (+)
4 GND USB Power Ground
Table 3-14 S-Video OUT Connector (4 pin)
Pin No Output Signal Description
1
SVIDEO OUT/IN YG Y (Luma) GND
2
SVIDEO OUT/IN CG C (Chroma) GND
3
SVIDEO OUT/IN Y Y (Luma) Signal
4
SVIDEO OUT/IN C C (Chroma) Signal
Table 3-15 Monitor Power (16 pin)
Pin No Description
2, 3, 7, 10, 15
12V
1, 5, 8, 9, 11, 16
GND
6 / 14
USB 1- / USB 1+
4, 12, 13
NC (no connection)
