GE Voluson E6

GE HEALTHCARERAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
5-26 Section 5-3 - FrontEnd Processor
5-3-1 RTF- Probe Connector Board (cont’d)
Figure 5-7 Voluson E6: RTF + Beamformer (RTM)
RST Transmitter Subboard
RSR Receiver Subboard
+
RST Transmitter Subboard
RSR Receiver Subboard
+
RTF Probe Controlboard
Power
MOT - signals
CTRL - signals
Tx/Rx
Power
MOT - signals
CTRL - signals
Tx/Rx
Power
MOT - signals
CTRL - signals
Tx/Rx
256 Tx/Rx Channels (Rx Channels multiplexed)
SIN-COS, Mot-Strobes
CTRL-signals
PowerSupply
RTK Motherboard
EBF_D (18)
Probe 3 Probe 1Probe 2
RTM Beamformer Motherboard
RSW CW-Doppler Board
Rx /Tx
CW Probe
CH 129
CH 1
CH 1
CH 128
CH 256
CH 256
Voluson E6 - BT09
8 x RSR-Boards (16 channels) = 128 channels
16 x RST-Boards (16 channels) = 256 channels
32 Tx/Rx
Channels
CH 98 ... CH 128
1 channel
Voluson E6 - BT09
Voluson E6 - BT10
Voluson E6 - BT10
8 x RSR-Boards (16 channels) = 128 channels
12 x RST-Boards (16 channels) = 192 channels
