5-2-6 Data Location
The Voluson E8 / Voluson E6 Hard disk drive (HDD) is divided into 4 partitions:
C: System partition:
- Operating System (Windows XP) including all Windows settings (IP-address, Network Name,
etc.)
- US-Application Software (UISAPP)
- Global Service Platform Software
- Software Options
D: User partition:
- User Presets (Backup) database
- Images (Archive), Patient-ID´s and Reports database
- Service database
- System settings database
R: Rescue partition:
- Factory Images of C:Partition for System recovery after HDD (Windows) crash
- Printer Drivers
LINUX partition: (not visible in Windows)
- Linux operating system for rescue functionality
• Distribution of partitions at 320 Gbyte HDD (BT09 and BT10)
• Distribution of partitions at 500 Gbyte HDD (BT12/BT13)
System
(~ 7 GB)
USER
(~283 GB)
Linux
(~ 155MB)
Rescue
(~ 8 GB)
System
(~ 12 GB)
USER
(~ 470 GB)
Linux
(~ 273MB)
Rescue
(~ 16 GB)
