GE HEALTHCARERAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
5-68 Section 5-14 - Common Service Desktop (CSD)
5-14-2 Error Logs
When the Error Logs page is selected, different log viewing options are available.
Log Viewer is displayed in a separate window.
5-14-3 Diagnostics
The Diagnostic page uses a web-controlled user interface to provide access to common service
components and perform diagnostics.
• Non-Interactive: The tests are performed without the user’s intervention.
• Interactive: The user is required to perform an operation on the ultrasound system in order for the
test to be completed successfully. This option is not applicable when used remotely.
Figure 5-41 Common Service Desktop - Error Logs
Figure 5-42 Common Service Desktop - Diagnostics
